Plastic Processed: | PE, HDPE | Output (kg/h): | 200 - 500 |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Core Components: | Gearbox, Motor | Screw Design: | Single Screw |
Voltage: | Customzied | Dimension(l*w*h): | 10000*1000*1300 |
Power (kw): | 132 | Warranty: | 1 Year |
Weight (KG): | 5000 | Applicable Material: | PP PE LDPE HDPE Film |
Final Product: | Clean Plastic Pellet | Color: | Customer Choice |
Rotate Speed: | 10-60r/min | Long Dia.ratio: | 16:1,10:1 |
Screw Dia: | 250mm,180mm |
Model | Screw dia.(mm) | Long dia. ratio | Output(kg/h) | Power(kw) | Rotate speed(r/min) |
LDF-SJP-125-105 | Ø125,Ø105 | 16:1,10:1 | 100-120 | 30/15 | 10-60 |
LDF-SJP-145-110 | Ø145,Ø110 | 16:1,10:1 | 160-200 | 45/18.5 | 10-60 |
LDF-SJP-160-120 | Ø160,Ø120 | 16:1,10:1 | 200-250 | 55/22 | 10-60 |
LDF-SJP-180-130 | Ø180,Ø130 | 16:1,10:1 | 220-270 | 75/30 | 10-60 |
LDF-SJP-215-150 | Ø215,Ø150 | 16:1,10:1 | 250-300 | 90/30 | 10-60 |
LDF-SJP-250-180 | Ø250,Ø180 | 16:1,10:1 | 400-500 | 132/37 | 10-60 |
